Motorola SLR5500 UHF
4.529,14 €
Beschreibung
Produktbeschreibung für den Motorola MOTOTRBO™ SLR 5500 Repeater
Der MOTOTRBO™ SLR 5500 Repeater ist die ideale Lösung für Unternehmen, die auf eine zuverlässige Sprach- und Datenkommunikation angewiesen sind. Dieser Repeater kombiniert hohe Leistung mit moderner Technologie, um den Kommunikationsanforderungen moderner Arbeitsumgebungen gerecht zu werden. Dank seines schlanken Designs und seines geringen Stromverbrauchs eignet sich der SLR 5500 perfekt für den Einsatz in unterschiedlichsten Branchen, von der Fabrikhalle bis hin zum Außendienst.
Hauptmerkmale:
- Hochleistung und Zuverlässigkeit: 50 W Sendeleistung, hervorragende Sprachqualität auch unter widrigen Bedingungen, ideal für große Areale.
- Zukunftssichere Technologie: Erweiterbare Module, 10x mehr Prozessorleistung, 15x mehr Speicher und 125x mehr Datenspeicher im Vergleich zur Vorgängergeneration.
- Hocheffizient: Energieeffizient durch neueste HF-Technologie, geringer Platzbedarf und niedrige Betriebskosten.
- Vielseitige Kompatibilität: Unterstützt alle MOTOTRBO-Systemarchitekturen wie Single Site Conventional, IP Site Connect, Capacity Plus und mehr.
- Einfache Wartung und Bedienung: Integriertes 3A-Akkuladegerät, Fernzugriffsmöglichkeiten und frontseitiger USB-Anschluss für einfache Konfiguration.
- Robustes Design: Entwickelt für den Einsatz in anspruchsvollen Umgebungen mit einem Betriebstemperaturbereich von -30 bis +60°C.
Technische Daten:
- Leistung: 1-50 Watt
- Frequenz: 403-470 MHz
- Kanäle: 64
- SuperSlim: Geringer Platzverbrauch
- Rx/Tx Anschlüsse: Rx: BNC-Buchse; Tx: N-Buchse
- Inklusive: Stromkabel (EU) (Eingebautes 230V Netzteil)
Eigenschaften
| Artikelart: | Repeater |
|---|---|
| Betriebsart: | DMR & analog |
| Frequenz: | UHF (403-527 MHz) |
| Serie: | SLR5000 |
Hier finden sie unsere Produkt Downloads.
Zubehör
Lizenzschlüssel um die Capacity Plus Single Site-Funktion in einem DR 3000-/SLR 5500-Repeater zu aktivieren. Capacity Plus Single Site provides a single site trunking solution for up to 40 channels (i.e. 20 repeaters*) with a maximum of 16 Trunked channels (i.e. 8 Trunked repeaters*) / 24 Data Revert channels (i.e. 12 Data Revert repeaters*) All Trunked and Data Revert repeaters in a Capacity Plus Single Site system need to have the Capacity Plus Single Site feature activated using the CPS and this requires the purchase of a separate license key for each repeater*. *Note: Excludes Digital Voting Satellite Receivers.
Lizenzschlüssel um die Digital Telephone Patch Funktion in einem DR 3000 / SLR 5500 Repeater zu aktivieren. Digital Telephone Patch enables MOTOTRBO digital system users to place and receive telephone calls which are routed via a gateway between a landline telephone network and MOTOTRBO radio system. Each phone gateway repeater in the system needs to have the Digital Telephone Patch feature activated using the CPS and this requires the purchase of a separate license key for each phone gateway repeater.
Lizenzschlüssel um die Capacity Plus Multi Site-Funktion in einem SLR1000 / SLR5500 Repeater zu aktivieren, bei dem die Capacity Plus Single Site-Funktion zuvor schon aktiviert wurde. Capacity Plus Multi Site provides a multi-site trunking solution for up to 15 sites and 24 channels (i.e. 12 repeaters*) per site with a maximum of 16 Trunked channels (i.e. 8 Trunked repeaters*) / 22 Data Revert channels (i.e. 11 Data Revert repeaters*) per site. All Trunked and Data Revert repeaters in a Capacity Plus Multi Site system need to have the Capacity Plus Multi Site feature activated using the CPS and this requires the purchase of a separate license key for each repeater*. *Note: Excludes Digital Voting Satellite Receivers
Lizenzschlüssel um die Capacity Plus Multi Site-Funktion in einem SLR1000 / SLR55000-Repeater zu aktivieren, bei dem die Capacity Plus Single Site-Funktion zuvor NICHT aktiviert wurde. Capacity Plus Multi Site provides a multi-site trunking solution for up to 15 sites and 24 channels (i.e. 12 repeaters*) per site with a maximum of 16 Trunked channels (i.e. 8 Trunked repeaters*) / 22 Data Revert channels (i.e. 11 Data Revert repeaters*) per site. All Trunked and Data Revert repeaters in a Capacity Plus Multi Site system need to have the Capacity Plus Multi Site feature activated using the CPS and this requires the purchase of a separate license key for each repeater*. IMPORTANT NOTE: This FULL Capacity Plus Multi Site licence does NOT support Capacity Plus Single Site channels, so if a repeater needs also to support Capacity Plus Single Site channels then a Capacity Plus Single Site / Incremental Capacity Plus Multi Site licence combination should be purchased instead. *Note: Excludes Digital Voting Satellite Receivers.
License key required to activate the "Network Application Interface for Voice/CSBK" feature in a DR 3000 / SLR 5500 repeater. NAI for Voice/CSBK is an IP based interface that enables voice consoles to transmit and receive voice/CSBK calls to the radio system directly through the repeater. Where a wireline voice console is required to interface to a given system site then all voice capable repeaters* at that site must have their "Network Application Interface for Voice/CSBK" feature enabled using the CPS. Where a wireline voice console is not required to interface to a given system site, then repeaters at that site do not need to have this feature enabled. Voice capable repeaters are all repeaters except for data revert repeaters and repeaters where both slots are GPS revert slots *Note: Excludes Digital Voting Satellite Receivers.
License key required to activate the "Network Application Interface for Data" feature in a DR 3000 / SLR 5500 repeater. NAI for Data is an IP based interface that enables data applications using the MNIS (MOTOTRBO Network Interface Service) data gateway to transmit and receive data calls to the radio system directly through the repeater. Where an MNIS is required to interface to a given system site then all repeaters* at that site must have their "Network Application Interface for Data" feature enabled using the CPS. Where an MNIS is not required to interface to a given system site, then repeaters at that site do not need to have this feature enabled. *Note: Excludes Digital Voting Satellite Receivers.
Licence key required to activate the Digital Voting feature in a DR 3000 / SLR 5500 repeater. Digital Voting employs multiple Satellite Receivers (i.e. repeaters configured for "receive-only") to relay radio transmissions to a central Voting Repeater in order to address the Inbound / Outbound range mismatches that can arise due to the different radio / repeater radiated power levels. Only the Voting Repeaters in a system (not the Satellite Receivers) need to have the Digital Voting feature activated using the CPS and this requires the purchase of a separate license key for each Voting Repeater.
Lizenz für den Einzelfrequenzbetrieb für die Repeater Motorola SLR5500 und SLR1000.Repeaterbetrieb möglich ohne Duplexfrequenz! Die Umsetzung erfolgt über die beiden DMR Zeitschlitze, in dieser Betriebsart ist nur ein Gespräch zur Zeit möglich.für SLR1000 ist das PMLN7263A Antennen-Umschalt-Kit für den Einbau in den Repeater verfügbar
