Motorola SLR1000 VHF
3.962,70 €
Beschreibung
Produktbeschreibung für den Motorola MOTOTRBO™ SLR 1000 Repeater
Der MOTOTRBO™ SLR 1000 Repeater ist eine robuste und zuverlässige Lösung für Kommunikationssysteme, die maximale Abdeckung bei minimalem Platzbedarf erfordern. Mit seiner widerstandsfähigen Konstruktion und den vielseitigen Einsatzmöglichkeiten eignet er sich ideal sowohl für den Innen- als auch für den Außeneinsatz. Dank seiner kompakten Bauweise kann der Repeater problemlos in bestehenden Systemen integriert werden, um die Reichweite zu erweitern und die Kommunikationsqualität zu optimieren.
Hauptmerkmale:
- Hochleistung und Zuverlässigkeit: Sendeleistung von 1 bis 10 Watt für klare und stabile Kommunikation über große Distanzen.
- Zukunftssichere Technologie: Unterstützt alle gängigen MOTOTRBO-Systemarchitekturen wie IP Site Connect, Capacity Plus und mehr.
- Robustes Design: IP65-zertifiziert, widersteht extremen Temperaturen von -30°C bis +60°C, ideal für den Einsatz in rauen Umgebungen.
- Platzsparendes Design: Dank seiner kompakten Maße lässt sich der SLR 1000 problemlos an beengten Standorten installieren.
- Einfache Wartung und Bedienung: USB-Anschluss und Ethernet-Konnektivität ermöglichen eine schnelle und unkomplizierte Konfiguration.
- Einbaumöglichkeit für einen Duplexfilter vorhanden. (Einbausatz optional erhältlich, Artikel: 103235)
Eckdaten:
- Indoor / Outdoor: Flexibel einsetzbar in verschiedenen Umgebungen
- Leistung: 1-10 Watt
- Frequenz: 136-174 MHz
- Kanäle: 64
- Schutzklasse: IP65 (staubdicht und wasserfest)
- Inklusive: Outdoornetzteil, Wandhalterung
Eigenschaften
| Artikelart: | Repeater |
|---|---|
| Betriebsart: | DMR & analog |
| Frequenz: | VHF (136-174 MHz) |
| Serie: | SLR1000 |
Hier finden sie unsere Produkt Downloads.
Zubehör
Lizenzschlüssel um die Capacity Plus Single Site-Funktion in einem DR 3000-/SLR 5500-Repeater zu aktivieren. Capacity Plus Single Site provides a single site trunking solution for up to 40 channels (i.e. 20 repeaters*) with a maximum of 16 Trunked channels (i.e. 8 Trunked repeaters*) / 24 Data Revert channels (i.e. 12 Data Revert repeaters*) All Trunked and Data Revert repeaters in a Capacity Plus Single Site system need to have the Capacity Plus Single Site feature activated using the CPS and this requires the purchase of a separate license key for each repeater*. *Note: Excludes Digital Voting Satellite Receivers.
Lizenzschlüssel um die Digital Telephone Patch Funktion in einem DR 3000 / SLR 5500 Repeater zu aktivieren. Digital Telephone Patch enables MOTOTRBO digital system users to place and receive telephone calls which are routed via a gateway between a landline telephone network and MOTOTRBO radio system. Each phone gateway repeater in the system needs to have the Digital Telephone Patch feature activated using the CPS and this requires the purchase of a separate license key for each phone gateway repeater.
Lizenzschlüssel um die Capacity Plus Multi Site-Funktion in einem SLR1000 / SLR5500 Repeater zu aktivieren, bei dem die Capacity Plus Single Site-Funktion zuvor schon aktiviert wurde. Capacity Plus Multi Site provides a multi-site trunking solution for up to 15 sites and 24 channels (i.e. 12 repeaters*) per site with a maximum of 16 Trunked channels (i.e. 8 Trunked repeaters*) / 22 Data Revert channels (i.e. 11 Data Revert repeaters*) per site. All Trunked and Data Revert repeaters in a Capacity Plus Multi Site system need to have the Capacity Plus Multi Site feature activated using the CPS and this requires the purchase of a separate license key for each repeater*. *Note: Excludes Digital Voting Satellite Receivers
Lizenzschlüssel um die Capacity Plus Multi Site-Funktion in einem SLR1000 / SLR55000-Repeater zu aktivieren, bei dem die Capacity Plus Single Site-Funktion zuvor NICHT aktiviert wurde. Capacity Plus Multi Site provides a multi-site trunking solution for up to 15 sites and 24 channels (i.e. 12 repeaters*) per site with a maximum of 16 Trunked channels (i.e. 8 Trunked repeaters*) / 22 Data Revert channels (i.e. 11 Data Revert repeaters*) per site. All Trunked and Data Revert repeaters in a Capacity Plus Multi Site system need to have the Capacity Plus Multi Site feature activated using the CPS and this requires the purchase of a separate license key for each repeater*. IMPORTANT NOTE: This FULL Capacity Plus Multi Site licence does NOT support Capacity Plus Single Site channels, so if a repeater needs also to support Capacity Plus Single Site channels then a Capacity Plus Single Site / Incremental Capacity Plus Multi Site licence combination should be purchased instead. *Note: Excludes Digital Voting Satellite Receivers.
License key required to activate the "Network Application Interface for Voice/CSBK" feature in a DR 3000 / SLR 5500 repeater. NAI for Voice/CSBK is an IP based interface that enables voice consoles to transmit and receive voice/CSBK calls to the radio system directly through the repeater. Where a wireline voice console is required to interface to a given system site then all voice capable repeaters* at that site must have their "Network Application Interface for Voice/CSBK" feature enabled using the CPS. Where a wireline voice console is not required to interface to a given system site, then repeaters at that site do not need to have this feature enabled. Voice capable repeaters are all repeaters except for data revert repeaters and repeaters where both slots are GPS revert slots *Note: Excludes Digital Voting Satellite Receivers.
License key required to activate the "Network Application Interface for Data" feature in a DR 3000 / SLR 5500 repeater. NAI for Data is an IP based interface that enables data applications using the MNIS (MOTOTRBO Network Interface Service) data gateway to transmit and receive data calls to the radio system directly through the repeater. Where an MNIS is required to interface to a given system site then all repeaters* at that site must have their "Network Application Interface for Data" feature enabled using the CPS. Where an MNIS is not required to interface to a given system site, then repeaters at that site do not need to have this feature enabled. *Note: Excludes Digital Voting Satellite Receivers.
Licence key required to activate the Digital Voting feature in a DR 3000 / SLR 5500 repeater. Digital Voting employs multiple Satellite Receivers (i.e. repeaters configured for "receive-only") to relay radio transmissions to a central Voting Repeater in order to address the Inbound / Outbound range mismatches that can arise due to the different radio / repeater radiated power levels. Only the Voting Repeaters in a system (not the Satellite Receivers) need to have the Digital Voting feature activated using the CPS and this requires the purchase of a separate license key for each Voting Repeater.
Lizenz für den Einzelfrequenzbetrieb für die Repeater Motorola SLR5500 und SLR1000.Repeaterbetrieb möglich ohne Duplexfrequenz! Die Umsetzung erfolgt über die beiden DMR Zeitschlitze, in dieser Betriebsart ist nur ein Gespräch zur Zeit möglich.für SLR1000 ist das PMLN7263A Antennen-Umschalt-Kit für den Einbau in den Repeater verfügbar
